Standart Towel Radiators

White Straight

Usage
Practical Use and Drying

Options
Flat and Oval Options

Efficiency
Ideal Heating and Drying Performance

Warmhaus White StraightTowels are always with you in areas such as kitchen and bathroom, as well as their simple and stylish appearance. While heating is provided, the need for drying in your bathrooms is also provided.

Height: 400 - 600 mm
Length: 500-1800 mm
Various height options from 600 mm to 1800 mm
Width model options: 400-500-600 mm
Test Pressure/Bar: 13 bar Max.
Water Temperature: 95°C
Color: White

Product Compare

Product Information Form

TECHNICAL DETAILS
USER MANUALS & DOCUMENTS

		Width	Height	Connection	Number of pipes	Pipe Diameter		Maximum Operating Temperature	Test Pressure	Maximum Working Pressure	HEAT EFFICIENCY TABLE △T = 50 K (75765720°)
Type	Measure	(A) mm	(H) mm	Distance				(°C)	(bar)	(bar)	WHITE (RAL 9016)
				(L) mm							Watt Kcal/h BTU/h
T100	400x600	400	600	356	11	22		120°C	13	10	224 193 764
T100	400x700	400	700	356	13	22		120°C	13	10	259 223 884
T100	400x800	400	800	356	14	22		120°C	13	10	283 243 965
T100	400x900	400	900	356	15	22		120°C	13	10	312 268 1064
T100	400x1000	400	1000	356	16	22		120°C	13	10	342 294 1167
T100	400x1100	400	1100	356	18	22		120°C	13	10	372 320 1269
T100	400x1200	400	1200	356	20	22		120°C	13	10	402 346 1371
T100	400x1300	400	1300	356	21	22		120°C	13	10	435 374 1484
T100	400x1400	400	1400	356	22	22		120°C	13	10	468 403 1597
T100	400x1500	400	1500	356	24	22		120°C	13	10	501 431 1709
T100	400x1600	400	1600	356	26	22		120°C	13	10	534 459 1822
T100	400x1700	400	1700	356	28	22		120°C	13	10	573 493 1955
T100	400x1800	400	1800	356	30	22		120°C	13	10	619 533 2112
T100	450x1000	450	1000	405	16	22		120°C	13	10
T100	450x1200	450	1200	405	20	22		120°C	13	10
T100	450x1600	450	1600	405	26	22		120°C	13	10
T100	450x1800	450	1800	405	30	22		120°C	13	10
T100	500x700	500	700	456	13	22		120°C	13	10	311	268	1061
T100	500x800	500	800	456	14	22		120°C	13	10	338	291	1153
T100	500x900	500	900	456	15	22		120°C	13	10	374	322	1276
T100	500x1000	500	1000	456	16	22		120°C	13	10	407	350	1389
T100	500x1100	500	1100	456	18	22		120°C	13	10	444	382	1515
T100	500x1200	500	1200	456	20	22		120°C	13	10	480	413	1638
T100	500x1300	500	1300	456	21	22		120°C	13	10	521	448	1777
T100	500x1400	500	1400	456	22	22		120°C	13	10	562	484	1917
T100	500x1500	500	1500	456	24	22		120°C	13	10	603	519	2057
T100	500x1600	500	1600	456	26	22		120°C	13	10	644	554	2197
T100	500x1700	500	1700	456	28	22		120°C	13	10	690	594	2354
T100	500x1800	500	1800	456	30	22		120°C	13	10	735	632	2508
T100	600x700	600	700	556	13	22		120°C	13	10	362	311	1235
T100	600x800	600	800	556	14	22		120°C	13	10	394	339	1344
T100	600x900	600	900	556	15	22		120°C	13	10	435	374	1484
T100	600x1000	600	1000	556	16	22		120°C	13	10	472	406	1610
T100	600x1100	600	1100	556	18	22		120°C	13	10	517	445	1764
T100	600x1200	600	1200	556	20	22		120°C	13	10	557	479	1900
T100	600x1300	600	1300	556	21	22		120°C	13	10	607	522	2071
T100	600x1400	600	1400	556	22	22		120°C	13	10	656	564	2238
T100	600x1500	600	1500	556	24	22		120°C	13	10	705	607	2405
T100	600x1600	600	1600	556	26	22		120°C	13	10	755	650	2576
T100	600x1700	600	1700	556	28	22		120°C	13	10	804	692	2743
T100	600x1800	600	1800	556	30	22		120°C	13	10	854	735	2913
OBI	620X800	620	800	570	17	22	30x40x1,5	120°C	13	10	N/A	N/A	N/A
OBI	620X1210	620	1210	570	26	22	30x40x1,5	120°C	13	10	N/A	N/A	N/A
OBI	620X1690	620	1690	570	36	22	30x40x1,5	120°C	13	10	N/A	N/A	N/A

Installation and User Manual

Product Brochure

White Straight
