Warmhaus Chrome Towel Rails have an elegant appearance and a high level of quality, they are available in flat and oval chrome-plated.Jul. With this product, you can have the pleasure of drying your towels while heating your bathroom.

  • Height: 400 - 600 mm
  • Length: 500-1800 mm
  • Various height options from 600 mm to 1800 mm
  • Width model options: 400-500-600 mm
  • Test Pressure/Bar: 13 bar Max.
  • Water Temperature: 95°C
  • Color: Crome
  Width height Connection Number of pipes Pipe Diameter   Maximum Operating Temperature Test Pressure Maximum Working Pressure HEAT EFFICIENCY TABLE
△T = 50 K (75765720°)
Type Measure (A) mm (H) mm Distance       (°C) (bar) (bar) CROME
        (L) mm             Watt Kcal/h BTU/h
T100 400x600 400 600 356 11 22   120°C 13 10 142   122   484
T100 400x700 400 700 356 13 22   120°C 13 10 166   143   566
T100 400x800 400 800 356 14 22   120°C 13 10 177   152   604
T100 400x900 400 900 356 15 22   120°C 13 10 198   170   675
T100 400x1000 400 1000 356 16 22   120°C 13 10 219   188   747
T100 400x1100 400 1100 356 18 22   120°C 13 10 240  206   819
T100 400x1200 400 1200 356 20 22   120°C 13 10 260  224   887
T100 400x1300 400 1300 356 21 22   120°C 13 10 285  245   972
T100 400x1400 400 1400 356 22 22   120°C 13 10 309  266   1054
T100 400x1500 400 1500 356 24 22   120°C 13 10 334   287   1139
T100 400x1600 400 1600 356 26 22   120°C 13 10 347  299   1184
T100 400x1700 400 1700 356 28 22   120°C 13 10 383  330   1307
T100 400x1800 400 1800 356 30 22   120°C 13 10 407  350   1389
T100 450x1000 450 1000 405 16 22   120°C 13 10
T100 450x1200 450 1200 405 20 22   120°C 13 10
T100 450x1600 450 1600 405 26 22   120°C 13 10
T100 450x1800 450 1800 405 30 22   120°C 13 10
T100 500x700 500 700 456 13 22   120°C 13 10 202 174 689
T100 500x800 500 800 456 14 22   120°C 13 10 218 188 744
T100 500x900 500 900 456 15 22   120°C 13 10 242 208 826
T100 500x1000 500 1000 456 16 22   120°C 13 10 267 230 911
T100 500x1100 500 1100 456 18 22   120°C 13 10 291 250 993
T100 500x1200 500 1200 456 20 22   120°C 13 10 315 271 1075
T100 500x1300 500 1300 456 21 22   120°C 13 10 344 296 1174
T100 500x1400 500 1400 456 22 22   120°C 13 10 372 320 1269
T100 500x1500 500 1500 456 24 22   120°C 13 10 400 344 1365
T100 500x1600 500 1600 456 26 22   120°C 13 10 427 367 1457
T100 500x1700 500 1700 456 28 22   120°C 13 10 456 392 1556
T100 500x1800 500 1800 456 30 22   120°C 13 10 484 416 1651
T100 600x700 600 700 556 13 22   120°C 13 10 239 206 815
T100 600x800 600 800 556 14 22   120°C 13 10 258 222 880
T100 600x900 600 900 556 15 22   120°C 13 10 286 246 976
T100 600x1000 600 1000 556 16 22   120°C 13 10 314 270 1071
T100 600x1100 600 1100 556 18 22   120°C 13 10 342 294 1167
T100 600x1200 600 1200 556 20 22   120°C 13 10 370 318 1262
T100 600x1300 600 1300 556 21 22   120°C 13 10 404 348 1378
T100 600x1400 600 1400 556 22 22   120°C 13 10 438 377 1494
T100 600x1500 600 1500 556 24 22   120°C 13 10 472 406 1610
T100 600x1600 600 1600 556 26 22   120°C 13 10 506 435 1726
T100 600x1700 600 1700 556 28 22   120°C 13 10 540 465 1842
T100 600x1800 600 1800 556 30 22   120°C 13 10 574 494 1958
OBI 620X800 620 800 570 17 22 30x40x1,5 120°C 13 10 N/A N/A N/A
OBI 620X1210 620 1210 570 26 22 30x40x1,5 120°C 13 10 N/A N/A N/A
OBI 620X1690 620 1690 570 36 22 30x40x1,5 120°C 13 10 N/A N/A N/A
