Warmhaus Chrome Oval Towels offer all the advantages brought by stainless steel in addition to bringing elegance to the spaces with their aesthetic appearance. These products, which are more resistant to corrosion and overall life, meet different expectations with a wide range of designs. It is suitable for all kinds of central systems and electrical use with additional Octets.

  • Height: 400 - 600 mm
  • Length: 500-1800 mm
  • Various height options from 600 mm to 1800 mm
  • Width model options: 400-500-600 mm
  • Test Pressure/Bar: 13 bar Max.
  • Water Temperature: 95°C
  • Color: Crome
  Width height Connection Number of pipes Pipe Diameter   Maximum Operating Temperature Test Pressure Maximum Working Pressure HEAT EFFICIENCY TABLE
Type Measure (A) mm (H) mm Distance       (°C) (bar) (bar) △T = 50 K (75765720°)
        (L) mm             Watt Kcal/h BTU/h
T100 400x600 400 600 356 11 22   120°C 13 10 142   122   484
T100 400x700 400 700 356 13 22   120°C 13 10 166   143   566
T100 400x800 400 800 356 14 22   120°C 13 10 177   152   604
T100 400x900 400 900 356 15 22   120°C 13 10 198   170   675
T100 400x1000 400 1000 356 16 22   120°C 13 10 219   188   747
T100 400x1100 400 1100 356 18 22   120°C 13 10 240  206   819
T100 400x1200 400 1200 356 20 22   120°C 13 10 260  224   887
T100 400x1300 400 1300 356 21 22   120°C 13 10 285  245   972
T100 400x1400 400 1400 356 22 22   120°C 13 10 309  266   1054
T100 400x1500 400 1500 356 24 22   120°C 13 10 334   287   1139
T100 400x1600 400 1600 356 26 22   120°C 13 10 347  299   1184
T100 400x1700 400 1700 356 28 22   120°C 13 10 383  330   1307
T100 400x1800 400 1800 356 30 22   120°C 13 10 407  350   1389
T100 450x1000 450 1000 405 16 22   120°C 13 10
T100 450x1200 450 1200 405 20 22   120°C 13 10
T100 450x1600 450 1600 405 26 22   120°C 13 10
T100 450x1800 450 1800 405 30 22   120°C 13 10
T100 500x700 500 700 456 13 22   120°C 13 10 202 174 689
T100 500x800 500 800 456 14 22   120°C 13 10 218 188 744
T100 500x900 500 900 456 15 22   120°C 13 10 242 208 826
T100 500x1000 500 1000 456 16 22   120°C 13 10 267 230 911
T100 500x1100 500 1100 456 18 22   120°C 13 10 291 250 993
T100 500x1200 500 1200 456 20 22   120°C 13 10 315 271 1075
T100 500x1300 500 1300 456 21 22   120°C 13 10 344 296 1174
T100 500x1400 500 1400 456 22 22   120°C 13 10 372 320 1269
T100 500x1500 500 1500 456 24 22   120°C 13 10 400 344 1365
T100 500x1600 500 1600 456 26 22   120°C 13 10 427 367 1457
T100 500x1700 500 1700 456 28 22   120°C 13 10 456 392 1556
T100 500x1800 500 1800 456 30 22   120°C 13 10 484 416 1651
T100 600x700 600 700 556 13 22   120°C 13 10 239 206 815
T100 600x800 600 800 556 14 22   120°C 13 10 258 222 880
T100 600x900 600 900 556 15 22   120°C 13 10 286 246 976
T100 600x1000 600 1000 556 16 22   120°C 13 10 314 270 1071
T100 600x1100 600 1100 556 18 22   120°C 13 10 342 294 1167
T100 600x1200 600 1200 556 20 22   120°C 13 10 370 318 1262
T100 600x1300 600 1300 556 21 22   120°C 13 10 404 348 1378
T100 600x1400 600 1400 556 22 22   120°C 13 10 438 377 1494
T100 600x1500 600 1500 556 24 22   120°C 13 10 472 406 1610
T100 600x1600 600 1600 556 26 22   120°C 13 10 506 435 1726
T100 600x1700 600 1700 556 28 22   120°C 13 10 540 465 1842
T100 600x1800 600 1800 556 30 22   120°C 13 10 574 494 1958
OBI 620X800 620 800 570 17 22 30x40x1,5 120°C 13 10 N/A N/A N/A
OBI 620X1210 620 1210 570 26 22 30x40x1,5 120°C 13 10 N/A N/A N/A
OBI 620X1690 620 1690 570 36 22 30x40x1,5 120°C 13 10 N/A N/A N/A
