Dimensions
Capacity
Control Panel
Sound Level
Modulation Rate
EfficiencyWith a 12-liter capacity, it provides maximum hot water efficiency with minimum size. Along with easy and safe usage, it ensures excellent performance with low energy consumption.
| TECHNICAL DATA | UNIT | WARMHAUS | |
| Gas type | (G20) | G31 | |
| Gas Supply Pressure | mbar | 20 | 37 |
| Gas Category | I2H I2H, I2E, I2E(S), I3P, II2E3P, II2E(S)3P, II2H3P, II2E+3P. | ||
| Rated Heat Load (Minimum) | kW | 10.0 | 10 |
| Rated Heat Load (Maximum) | kW | 23.5 | 23,5 |
| Rated Heat Power (Minimum) | kW | 8.90 | 8,95 |
| Rated Heat Power (Maximum) | kW | 20.7 | 20,6 |
| Efficiency (Minimum) | % | 89.2 | 89,5 |
| Efficiency (Maximum) | % | 88.1 | 87,62 |
| Gas Consumption (minimum) | m3/h | 1.03 | 0,4 |
| Gas Consumption (maximum) | m3/h | 2.43 | 0,959 |
| Nozzles | 85 | 50 | |
| NOx | Grade | 6 | 6 |
| NOx | mg/kWh | 37.7 | 26 |
| Hot water Load profile | Load Profile | L | |
| Seasonal Efficiency | % | 77 | |
| Seasonal Efficiency Class | Grade | A | |
| Minimum Water Flow | ℓ/min. | 3 | |
| Maximum Water Capacity (ΔT=25 °C) | ℓ/min. | 12 | |
| Sound Level | dB | 48 | |
| Water Pressure (max.) | bar | 10 | |
| Water Pressure (min.) | bar | 0.5 | |
| Setting Range | oC | 35-60 | |
| Power Supply | V AC | 230 V +10%;-15%, 50 Hz | |
| Electrical Protection Class | IPX4D | ||
| Electric Consumption | W | 20 - 30 | |
| Waste Gas Temperature (min.-max.) | oC | 110 - 190 | |
| Flue type | C12, C32 C42, C52, C62, C82, B22, B22P |
||
| Flue mass flow rate (min./max) | g/s | 9 / 13 | |
| Dimensions | mm | 638 x 336 x 242 | |
| Volume of Device | Liter | 51.9 | |
| Weight, Net | kg | 15 | |
| Weight, Gross | kg | 17 | |
| MAINTENANCE | |||
| To ensure correct operation over time, the appliance should be checked | |||
With a 12-liter capacity, it provides high efficiency and maximum comfort. It ensures uninterrupted hot water supply.
It takes up minimal space in your home while delivering high performance alongside its compact design.
It ensures excellent air circulation without the need for additional parts during flue connection and provides the most accurate disposal of exhaust gases into the environment.
Thanks to the powerful and modulating operation of the built-in fan, it ensures minimum electricity consumption.
Aquwa, which has the lowest NOx emissions in exhaust gases (Class 6), provides an environmentally friendly usage.
It continues to produce uninterrupted hot water to prevent temperature fluctuations that may occur due to changes in temperature and flow during hot water usage. This way, it provides comfortable hot water for use, ranging from 3 to 12 liters per minute, without experiencing hot/cold fluctuations.
